Scotch Rubber Splicing Tape 23, 3/4 in x 30 ft, Black, 1 roll/carton, 20 rolls/case

Manufactured by:
3M

9efdd7a5182133f9bf6491d93ff9aeb8439fd6a7 medium
Nuova Elva code
7000007286
Availability
Send request for quotation

Scotch Rubber Splicing Tape 23 is a thick, premium-grade rubber splicing tape composed of a self-fusing ethylene-propylene rubber (EPR) backing on a removable polyethylene liner. For best results when using this tape, apply it in successive, half-lapped layers by highly stretching it reducing the tape width to a minimum of 34 the original width throughout the entire application until the required build-up is reached to produce a uniform winding. Scotch Rubber Splicing Tape 23 is self-certified to ASTM D4388 Type III and is ROHS compliant; for more compliance information, visit www.3m.com/regs.

Features

  • Scotch Rubber Splicing Tape 23, Premium Grade, Self-Fusing EPR Backing, Removable Liner, Black Color, 30 mil, 3/4 in x 30 ft, 1 Roll/Carton, 20 Rolls/Case

  • PREMIUM GRADE TAPE: Commonly used as primary insulation for solid dielectric insulated cable splice and termination applications up to 69 kV

  • SPECIAL POLYESTER LINER: Lining keeps tape protected and clean during application and will not stick to the tape upon unwind

  • TEMPERATURE RANGE: Operating Temperature rated to 90 °C (194 °F), Emergency Overload rating of 130 °C (266 °F)

  • HALOGEN-FREE ADHESIVE: Halogen free per the International Electrotechnical Commission Standard

  • CERTIFICATION: Self-certified to ASTM D4388 Type III and ROHS Compliant

Specifications

Specifications

Country of OriginBrazil
Item StatusActive
