CR-P/M 42C Pluggable module diode and LED red, 110VDC, A1+, A2-
- Produttore:
- ABB
- Prezzo (IVA esclusa)
- € 4.32
- Codice Nuova Elva
- 1SVR405652R9000
- Codice produttore
- 1SVR405652R9000
- Disponibilità
- Invia RdO
The CR-P/M 42C plug-in module is a pluggable function module for the CR-P and CR-M range sockets. This module provides reverse polarity protection/free wheeling diode and a red LED indication. The rated control supply voltage is 110 V DC.
Specifiche tecniche
Dimensions | |
|---|---|
| Product Net Width | 13 mm |
| Product Net Height | 24 mm |
| Product Net Depth / Length | 9 mm |
| Product Net Weight | 0.003 kg |
Technical | |
| Output | none |
| Output Signal | none |
| Standards | CAN/CSA C22.2 No.14IEC/EN 63000IEC/EN 61984UL 508 |
| Function | Accessory for interface relays CR-MAccessory for interface relays CR-P |
| Sub-Function | Pluggable function module for pcb and miniature relay sockets |
| Sub-Function 2 | Reverse polarity protectionFree-wheeling diodered LED |
| Rated Control Supply Voltage (Us) | 110 V DC |
Classifications | |
| Object Classification Code | K |
| ETIM 9 | EC002586 - Accessories/spare parts for switching relay |
| eClass | V11.0 : 27371692 |
Environmental | |
| RoHS Status | Following EU Directive 2011/65/EU |
Ordering | |
| Minimum Order Quantity | 10 piece |
| Customs Tariff Number | 85411000 |
